swirliemc said:
Haha yeah i hear you I wouldn't stick my unit in the fridge either. The repair took about 20 mins. I was being extra careful to make sure I saved the screws and didn't touch the circuit board. Removing the cylinder was probably the hardest part because it was wedged in there pretty good. It took a little patience and a little wiggling, but it finally came free. All in all it was an easy repair. Also, the rubber feet did go back on without any adhesive. They seemed to have a decent amount of tackiness and stuck on with ease.
I dont expect the repair to be too difficult as i build and repair pc's.
This is the contents of the email from Arizer of how t do the repair. (very simple)
1./ Remove 4 rubber feet on bottom of base.
2./ Unscrew the 4 screws located under each rubber foot.
3./ Remove bottom base cover.
4./ Locate 2 screws only, one on either side of the circuit board (do not remove any screws that secure down the circuit boards).
Remove these 2 screws that secure the stainless steel cylinder down, and remove the cylinder (*Note: if it is tough to remove the
cylinder - wiggle the cylinder back and forth until it becomes loose and comes off - be careful not to touch the circuit board to prevent
any damage).
5./ When you have the cylinder off you will see the ceramic heater. Remove the long screw that secures the glass heater cover and
remove any broken glass particles by gently blowing canned air and/or turning it upside down and gently shake it so any glass
will fall out (*Note: when shaking the unit so any glass particles fall out - hold the ceramic heating element to prevent any damage).
6./ Once it is all cleaned out, place the new replacement glass heater cover in place and secure it with the long bottom screw/pin
(Note: make sure the holes in the cradle and glass heater cover are lined up to prevent breaking/cracking the glass). Make sure
before installing the new heater cover to put the insulation tube around the glass heater cover first.
7./ Now screw in the top 4 support screws evenly which center and support/holds the glass heater cover (*Note: do not screw in the 4
support screws too tight to prevent damage to the glass heater cover).
8./ Place the cylinder back on - line up the holes in the cylinder with the holes in the base. Position the cylinder top hole so it is
centered with the top of the glass heater cover. Secure the 2 screws that hold the cylinder in place.
9./ Place/center the base cover back on and screw in the 4 screws and place the 4 rubber feet back on.
Also I asked about the fact of doing the repair myself voiding the warranty this was the response back i got the part from debbie
"4. By doing the repair myself does that void any further warranty on the unit? - No this does not void your warranty as I am giving you permission to open your unit and this is why you purchase this part through me vs. ordering online - all is noted in your file."
I dont know if that means if you get the part from another retailer and do the repair yourself if that voids the warranty. The price is the same including shipping as most retailers its just coming from Canada.
Either way be cautious and EMAIL ARIZER SEEKING permission to do the repair so you dont void the warranty.
