Discontinued 2ZM by Herbaltherm

ADULTSWIM

ADULTSWIM

All Kids Outta The Pool!
If anyone has an idea or leads as to a mesh that will work as a coil please post or DM me.

ADULTSWIM,
Psyentist

Psyentist

Well-Known Member
oddjobold

oddjobold

Vape swap shop
Yep I agree it's more like this

Hippie said:
From looking at the pics of units here on the forums, that needing glueing back together, with the coil showing
I think you want a thicker mesh
There's some examples here if you click on the stainless options on the left https://themeshcompany.com/shop/woven-wire-mesh/
Click to expand...

(Learnt from my Herbie experimentations)

My guess is its some kinda stainless steel.

Not easy to fold in to the zig zag shape. Let me know if you find a good way.

DgN'R

DgN'R

I'm No Superman!
You can find more information in the RBT open source thread:

RBT Open Source build

Made a quick sketch for yout triangular form-factor https://imgur.com/a/1dpx9 Nice!! That's awesome @Rat0 . You took my crayola drawing to a new level , lol . Looks fresh! Thank you !! If space permits (longer unit ) I'm thinking we could fit a knob for temp control similar to the Zion ) .. A...
fuckcombustion.com

It seems to me that Ryan gets his supplies here:

Standard mesh: https://www.mcmaster.com/products/mesh/filter-mesh-2~/

Or perforated: https://www.mcmaster.com/products/mesh/perforated-sheets-2~/

ADULTSWIM

ADULTSWIM

All Kids Outta The Pool!
Thank you all for the links/research.
The thickest mesh vape wire on elementvape site was the ss 1.20 Ohms and is not as wide cut as what ryan is using(.6inch). But i still do think that it will work as a replacement mesh.
My kalipper is telling me the mesh has a .50mm spacing.

ADULTSWIM,
  • Like
Reactions: Jedster
DgN'R

DgN'R

I'm No Superman!
oddjobold said:
as you have your heater exposed, what hole size do you think the mesh is?
Click to expand...
On my side, about the 2ZM, I have no idea because I haven't disassembled it (but I'm thinking of asking for a DIY 2ZM to replace the 4Mi and make a few modifications on this (like 21700 and the wiring under the heater (like a Milaana))), but I've done some research with the heater on my RBT Milaana 3 and I'm pretty sure it's this (on McMaster-Carr):

[Stainless Steel Wire Cloth] - [304 Stainless Steel]:

Part Number: 85385T92
Wire Dia.: 0.0055" -> 0.1397mm
Opening Size: 0.018" -> 0.4572mm
Open Area: 59%
Mesh Size: 42 x 42

Width: 0.546" -> 13.8684mm (23 opening size for 24 wire)
Length: To be determined!

Or this one:

[High-Volume Particle-Filtering Stainless Steel Wire Cloth] - [316 Stainless Steel]:

Part Number: 9230T58
Wire Dia.: 0.0055" -> 0.1397mm
Opening Size: 0.0183" -> 0.46482mm
Open Area: 59%
Mesh Size: 42 x 42

Width: 0.5529" -> 14.04366mm (23 opening size for 24 wire)
Length: To be determined!

My caliper indicates correctly the ⌀0.13mm wire. About the opening size, I've tried inserting a ⌀0.4mm wire in it and it leaves a gap. I made the same test with a ⌀0.5mm wire and it doesn't fit. It is therefore highly likely that the opening size will be ~0.45mm, as in previous specifications (according to my research, these are the only two sizes available with these specifications on McMaster-Carr).









I wanted to order a sample to compare them and be completely sure, but unfortunately McMaster-Carr recently changed its conditions and now refuses to sell to any customer outside the United States. Ryan (ironically, that's the name of the person I conversed with at McMaster-Carr) told me he had adopt a “conservative” approach :shrug: However, the product seems to be imported from the People's Republic of China and I will do some research on this subject to find an identical mesh supplier in China (I'd like to design my DIY 4Mi :p).

Please don't hesitate to share your ideas and creations with us! 😉
