Divine Tribe atty's

BabyFacedFinster

Anything worth doing, is worth overdoing.
If there is a mac version, does that mean you could somehow use an iphone to load the software?

BabyFacedFinster,

bizwaxzion

Enigmatic Cannabist
If there is a mac version, does that mean you could somehow use an iphone to load the software?
No, MacOS and IOS are different operating systems. I just reloaded my old mods with the latest AF for use with the V5. I don't have a windows based computer anymore - but I was able to get the tools to run in a windows VM on my mac. I've seen some google hits that suggest a chromebook will run VirtualBox, so depending on your technical skills, you could install VirtualBox and then create a windows VM to run the tools.


BabyFacedFinster

Anything worth doing, is worth overdoing.
Thanks for the suggestions guys. I'm just not that computer savvy. I might wait to see what deal Matt might have on a mod and V5 combo when they start selling.
When the time comes, I might ask Matt if he could setup the AF on a newly purchased mod. Is the new eleaf Rim C the best option for a single battery mod with the incoming V5?

BabyFacedFinster,

iammyself

Well-Known Member
Thanks for the suggestions guys. I'm just not that computer savvy. I might wait to see what deal Matt might have on a mod and V5 combo when they start selling.
When the time comes, I might ask Matt if he could setup the AF on a newly purchased mod. Is the new eleaf Rim C the best option for a single battery mod with the incoming V5?

I got the Rim-C, and kind of wish I didn't now. I was able to get Arctic Fox loaded on it. I am very computer savvy, and it was a chore with the Rim-C. The wattage mode to clean the donut doesn't work with AF on the Rim-C, at least for me. Other than the difficulty of getting AF on it, and not being able to clean with wattage mode, the Rim-C has worked great with the V4.

I never did try it without AF though, I didn't want a 10 second limit on my hits. As I understand it, the Rim-C with the stock firmware can only fire for 10 seconds when you hold the button down, and can't auto-fire at all. That's why I put AF on mine, and have the auto-fire set to 60 seconds.


zor

Well-Known Member
Man, I busted up two different quartz crucibles because the cap on my v4 would stuck on the o-ring (I removed one of the two). Back to titanium, my only gripe with that is that the cup wobbles a lot over time because the nut comes loose.


lazylathe

Almost there...
Man, I busted up two different quartz crucibles because the cap on my v4 would stuck on the o-ring (I removed one of the two). Back to titanium, my only gripe with that is that the cup wobbles a lot over time because the nut comes loose.
Always make sure you lubricate the o-rings. It's very important to prevent breaking the glass.


oldfool

Well-Known Member
Always make sure you lubricate the o-rings.
Peanut oil? Or saliva? :drool:

Are you using the newer (softer), green o rings ?
Went a little smaller with these. Had to really stretch them.
Fairly easy on/off, not for pocket carry.




RustyOldNail

SEARCH for the treasure...
O-Ring lubing....

I would often use a drop of PG, from ECig mixing, but mineral oil is good too, available everywhere. When I don’t plan to use a device for awhile, I remove items, extends o-ring life a bit, and no surprise STICKING.


lazylathe

Almost there...
@oldfool :rofl::rofl:
Whatever takes your fancy but something non toxic and oily would work well.
Even a little vaseline jelly goes a long way or chapstick if you have that handy.
So many options!

@RustyOldNail

Good tip about removing the o-rings when not in use!
It will keep them at their original diameter for longer as well.

Back when Glass Symphony was around, he sold a tube of lube. All natural oils in a stick form.
That is what I use until it ends.


divinetribe

We are trying our hardest to become Medical Grade
Manufacturer

OCT v5 UPDATE​



Divine Tribe News
The V5 will be here at the end of Oct for prototype customers and the middle of Nov 2021 for people who have ask to be put on the wait list.. The v5 will most likely not be available on the site, so email to be put on the waiting list.

for prototype customers ( who already have a v5) please email me now to let me know if your address is the same and if you received the knurled base or the older smooth jet stream base. (We have a spread sheet and our making notes ) If we do not get your email we will email you or text if needed to verify. To the people that ordered from herb cafe or Rec Vape UK they will be supplied with the updated parts as well for their proto customers, so email them to verify address is the same.

2nd shipment parts are lagging and i am a few days away from my manufacture getting a small batch of 1000 heaters to cover the prototype customers, I am also waiting on the all glass tops (we have two manufactures working on these now) we hope to have these around the same time as the heaters.

To make a long story short we are hoping to be mailing these final updated parts to our prototype customers in 10 to 15 days
What are you getting :

  • All glass thick vortex top
  • two new larger side and bottom heated cups (settings will need to be adjusted)
  • Softer copper screws
  • New designed spacer
  • New designed Metal Window top
  • Knurled base if you got the older smooth Jet Stream Base
  • video of updated parts
The First production will be limited to keep quality control and customer service smooth running. Please email matt@ineedhemp.com to ask to be put on the waiting list if you are interested


OF

Well-Known Member
I am at TCR 170 and 420F.
Apparently the next V5 heater will need a TCR value of 200 plus since it is a stronger heater.

I don't think so. The TCR value is based on the material used in the heater, not the total power. Typical metals have maybe 1/3% increase in resistance per degree C rise. To make it more confusing the values we enter are multiplied PPM (Parts per Million) such that 170 really means 1700 PPM, .17%. We just save a digit on the display.

If we want to go to say 200C, that's a 180C rise over a 20C cold temperature. Multiply that 180 by the .17% per degree and get a 30.6% rise, .650 ohms, assuming .500 to start. At that point the metal will be at 200C, no matter what the power.

So, if Matt uses the same material (which seems logical....) we need the same TCR value and target temperature. The max power number might change, but not TCR.

Regards to all.

OF


lazylathe

Almost there...
I don't think so. The TCR value is based on the material used in the heater, not the total power. Typical metals have maybe 1/3% increase in resistance per degree C rise. To make it more confusing the values we enter are multiplied PPM (Parts per Million) such that 170 really means 1700 PPM, .17%. We just save a digit on the display.

If we want to go to say 200C, that's a 180C rise over a 20C cold temperature. Multiply that 180 by the .17% per degree and get a 30.6% rise, .650 ohms, assuming .500 to start. At that point the metal will be at 200C, no matter what the power.

So, if Matt uses the same material (which seems logical....) we need the same TCR value and target temperature. The max power number might change, but not TCR.

Regards to all.

OF

I was told this directly from the manufacturer...
I am clueless as to how a mod actually works and just try different settings until I find one that works best for me.

If you check the Divine Tribe website, he has the recommended settings there.

"For settings i have a arctic fox profile i use at 40sec and then it turns off, TCR is 180 using 33w to 36w to get to 490f to 510f, email me for latest config"

And from email communication with Matt:
"For the new heaters i have been using My pico with the prototype firmware that has auto fire
it definitely takes a couple more watts more to power it up and the TCR I have set it to 200"


OF

Well-Known Member
I was told this directly from the manufacturer...
I am clueless as to how a mod actually works and just try different settings until I find one that works best for me.
Thanks, I actually 'caught' his comments and have been using the 180/390F formula currently. And, as I said, the mod multiples the two values and uses there product to set the real target temperature. You can raise (or lower) either, although we want the temperature make sense so we 'tweak' the TCR value. Matt is taking about a new cup and different mod with 'prototype' software and finding a new value by the same 'cut and try' process we all use anyway.

This is why I suspect the OP (which would be you...) is using 170 (about 5% lower) and 420 (the same percentage higher) so the product remains the same. FWIW we collectively 'fished' out 170 for the V2s. A value I still use in mine years later. I suspect the actual element materials are the same as used in V5?

We 'tweak' whatever we use until we get the results we want. As individuals. What settings others use are at best guidelines?

Regards,

OF

OF,
  • Like
Reactions: KeroZen

lazylathe

Almost there...
Thanks, I actually 'caught' his comments and have been using the 180/390F formula currently. And, as I said, the mod multiples the two values and uses there product to set the real target temperature. You can raise (or lower) either, although we want the temperature make sense so we 'tweak' the TCR value. Matt is taking about a new cup and different mod with 'prototype' software and finding a new value by the same 'cut and try' process we all use anyway.

This is why I suspect the OP (which would be you...) is using 170 (about 5% lower) and 420 (the same percentage higher) so the product remains the same. FWIW we collectively 'fished' out 170 for the V2s. A value I still use in mine years later. I suspect the actual element materials are the same as used in V5?

We 'tweak' whatever we use until we get the results we want. As individuals. What settings others use are at best guidelines?

Regards,

OF
I am beta testing the V5

lazylathe,
  • Like
Reactions: OF
